Product description
The KRINGS KVL lightweight shoring box is particularly suitable for use in small to medium-sized sewer construction projects. Thanks to its low weight, it can be handled optimally with smaller wheeled excavators, making it ideal for laying and renovating gas, water, telephone, and power lines, as well as for creating house connections. Lightweight struts, secured with bolts and safety clips, enable quick assembly and installation using the adjustment method. If necessary, the shoring system can be extended for greater trench depths by adding top boxes.
Advantages
- Low weight
- For small to medium-sized construction projects
- Ideal for handling with small wheeled excavators
- For inner-city use
- Installation using the adjustment method in stable soils
Key data
- Length: 2.50 m
- Height: 0.50 m
- Panel thickness: 60 mm
- Pipe culvert height: -
- Pipe clearance length: 2.19 m
- Clear width: 1.16 - 1.89 m
- Surface area: 1.25 m2
Recommended excavator:
- mobile excavator 9-13 t
Specification
- Product number
- 111150DL
- 111150DL
- Nein
- Nein
- mit Lifteröse
- Voll
- KRINGS KVL L=2,50 m x H=0,50 m (SP 70x1280) Aufsatzbox
- Nein
- Trench box type
- Top box
- Box height [m]
- 0.50
- Box length [m]
- 2.50
- Minimum clear width [m]
- 1.16
- Maximum pipe culvert length [m]
- 2.19
