Product description
Hydraulic vibrator MR 95 AVM
• Max. centrifugal force
Standard mode 870 kN
Amplitude mode 950 kN
Speed mode 800 kN
• Max. speed
Standard mode 2,300 rpm
Amplitude mode 2,030 rpm
Speed mode 2,575 rpm
• Eccentric moment
Standard mode 15 kgm
Amplitude mode 21.0 kgm
Speed mode 11 kgm
Clamping tongs MRZ 106
• Max. centrifugal force 1,060 kN
• Clamping force 1,280 kN
• Weight approx. 730 kg
• Clamping pressure 350 bar
ACS-2 rapid coupling system for MR
SilentVibro package
Additional equipment
Automatic/hydraulic rapid coupling
Air conditioning
• Max. centrifugal force
Standard mode 870 kN
Amplitude mode 950 kN
Speed mode 800 kN
• Max. speed
Standard mode 2,300 rpm
Amplitude mode 2,030 rpm
Speed mode 2,575 rpm
• Eccentric moment
Standard mode 15 kgm
Amplitude mode 21.0 kgm
Speed mode 11 kgm
Clamping tongs MRZ 106
• Max. centrifugal force 1,060 kN
• Clamping force 1,280 kN
• Weight approx. 730 kg
• Clamping pressure 350 bar
ACS-2 rapid coupling system for MR
SilentVibro package
Additional equipment
Automatic/hydraulic rapid coupling
- Mounting kit ACS-1 and 2 for guide slide and vibrator
- Mounted on the machine, comprising
- Multiple coupling block nut part and male part
- Attachment bracket for alignment of the multiple coupling block
Air conditioning
- Automatic climate control
- Tinted roof and side windows
Key data
Output: 370/430 kW
Max. pile length: 16 m
Max. tension force: 200 kN
Max. torque: 50 kNm
Last inspection: January 2, 2025
Emission class 5 / Tier IV final
Engine: C 13 B (Caterpillar)
Motor capacity: 430 kW (585 hp)
Country of manufacture: Germany
CE certificate
Transport dimensions:
Width: 3.00 m
Height: 3.30 m
Length without winch: 10.30 m
Length including winch: 11.60 m
Weight (without counterweight and winch): 40.30 t
Weight of winch: 0.80 t
Weight of counterweight: 4.10 t
Additional counterweight (optional): 2.00 t
Max. pile length: 16 m
Max. tension force: 200 kN
Max. torque: 50 kNm
Last inspection: January 2, 2025
Emission class 5 / Tier IV final
Engine: C 13 B (Caterpillar)
Motor capacity: 430 kW (585 hp)
Country of manufacture: Germany
CE certificate
Transport dimensions:
Width: 3.00 m
Height: 3.30 m
Length without winch: 10.30 m
Length including winch: 11.60 m
Weight (without counterweight and winch): 40.30 t
Weight of winch: 0.80 t
Weight of counterweight: 4.10 t
Additional counterweight (optional): 2.00 t
